Name: High Temperature Silicone Sheet Heat Resistance Pad Thermally Silicone Pad For AI Processors AI Servers
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIF500-40-11US
Price: 4.10 USD
Availability: InStock

Thuis Producten silicone thermisch stootkussen

High Temperature Silicone Sheet Heat Resistance Pad Thermally Silicone Pad For AI Processors AI Servers

Productdetails:

Plaats van herkomst:	China
Merknaam:	Ziitek
Certificering:	UL & RoHS
Modelnummer:	TIF500-40-11US

Betalen & Verzenden Algemene voorwaarden:

Min. bestelaantal:	1000 STUKS
Prijs:	0.1-10 USD/PCS
Verpakking Details:	241312cm Kartons
Levertijd:	3-5 werkdagen
Betalingscondities:	T/T
Levering vermogen:	1000000 pc's/maand

Contact

Gedetailleerde productomschrijving

Producten Naam:	Hittebestendigheidskussentje op hoge temperatuur van het siliconenblad Thermisch siliconenkussentje	Applicatie:	AI-processors AI-servers
Hardheid:	20 kust 00	Dikte:	3.2 g/cm3
Trefwoorden:	Thermisch siliconenkussen	Thermische geleidbaarheid:	4.0W/m-k
Kleur:	Donkergrijs	Dikte bereik:	0,25~5,0 mm /(0,010~0,20 inch)
Constructie & Samenstelling::	Keramisch gevuld siliconenelastomeer

High Temperature Silicone Sheet Heat Resistance Pad Thermally Silicone Pad For AI Processors AI Servers

Products Description

TIF^®500-40-11US Series is an ultra-soft thermal interface material designed specifically to protect precision components that are extremely sensitive to mechanical stress. This product combines high thermal conductivity with exceptional gel-level softness,achieving a perfectly low-stress fit. It is suitable for addressing issues such as large tolerances, uneven surfaces,and the susceptibility of precision components to mechanical damage in high-precision assemblies.

Features:

> High thermal conductivity
> Super soft and highly compliant
> Self-adhesive without the need for additional surface adhesives
> Available in varies thicknesses
> Broad range of hardnesses available
> Outstanding thermal performance

Applications:

> Power tools
> Network communication products
> Electric vehicle batteries
> Computer CPU/GPU Cooling
> New energy vehicle power systems

> Photovoltaic
> Signal communication
> New energy vehicle
> Motherboard chip
> Radiator
> Display card
> Mainboard/mother board
> Notebook

> Power supply
> Heat pipe thermal solutions
> Memory Modules

Typical Properties of TIF^®500-40-11US Series
Property	Value		Test method
Color	Dark gray		Visual
Construction & Compostion	Ceramic filled silicone elastomer		******
Density(g/cm³)	3.2		ASTM D792
Thickness Range(inch/mm)	0.010~0.020	0.030~0.200	ASTM D374
	(0.25~0.5)	(0.75~5.0)
Hardness	65 Shore 00	20 Shore 00	ASTM 2240
Recommended Operating Temperature	-40 to 200℃		******
Breakdown Voltage(V/mm)	≥5500		ASTM D149
Dielectric Constant	7.0 MHz		ASTM D150
Volume Resistivity	＞1.0X10¹² Ohm-meter		ASTM D257
Flame rating	V-0		UL 94 (E331100)
Thermal conductivity	4.0 W/m-K		ASTM D5470
	4.0 W/m-K		ISO22007

High Temperature Silicone Sheet Heat Resistance Pad Thermally Silicone Pad For AI Processors AI Servers 0

Product Specifications

Standard Thickness: 0.010" (0.25 mm)~0.200" (5.00 mm) with increments of 0.010" (0.25 mm)
Standard Size: 16"× 16" (406 mm×406 mm)

Component Codes:

Reinforcement Fabric: FG (Fiberglass).
Coating Options: NS1 (Non-adhesive treatment),
DC1 (Single-sided hardening).
Adhesive Options: A1/A2 (Single-sided/Double-sided adhesive).

The TIF series is available in custom shapes and various forms.
For other thicknesses or more information, please contact us.

High Temperature Silicone Sheet Heat Resistance Pad Thermally Silicone Pad For AI Processors AI Servers 1

Company Profile

With professional R&D capabilities and many year experiences in thermal interface material industry, Ziitek company own many unique formulations which are our core technologies and advantages. Our goal is to provide quality & competitive products to our customers worldwide aiming for long-term business cooperation.

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

FAQ:

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China

Q: How do I place an order?

A:1. Click the "Sent messages" button to continue with the process.

2. Fill out the message form by entering a subject line, and message to us.

This message should include any questions you might have about the products as well as your purchase requests.

3. Click the "Send" button when you are finished to complete the process and send your message to us

4. We will reply you as soon as possible with Email or online

Q: How do I request customized samples?

A: To request samples, you can leave us message on website, or just contact us by send email or call us.
